Implementing DDD Series: Persisting Value Objects using Entity Framework

Following up on my previous article on Modelling Business Primitives With Value Objects, where I showed how I like to encapsulate the inner value and protect it at all cause, and not directly expose it to external parties (external to the Value Object class). This of course poses a challenge when needing to persist the value, as I’ve effectively introduced a whole new type that is unknown to any libraries and frameworks, and its inner value is guarded.

Let’s take a look at how I often persist Value Objects in a typical business application, where Entity Framework is used on top of a relational database, business concepts are mapped to tables and columns inside those tables. In the case of Value Objects, they are mapped to one or more columns depending on the amount of information they carry. These columns have a data type, and we now step into the art of mapping types from the application layer to the types that are available from the persistence layer. To be fair, Entity Framework provides abstractions for the specific data types available in the database technology that we’ve chosen, but these abstractions can only be mapped back and forth between language primitives (e.g. your string, int, bool, datetime etc.) and not your newly defined business primitives in the form of Value Objects. And to make it worse, one of the ideas of the Value Object implementation is to hide the language primitive, so Entity Framework will have a hard time figuring out what to do, so we need to provide a bit of help.

ValueConverter to the rescue

A feature of Entity Framework is that you can specify a ValueConverter for types where you explicitly define how a language (or runtime) type should be converted to a database type. Common use cases are to force all datetime to be stored as UTC or to store enums as their string representation to make stored values more relatable when looking directly in the database (seeing a 1 or 3 might not be as relatable as seeing Pending or Failed in a status column).

Let’s use a ValueConverter to tell how Entity Framework should convert a Value Object into a database type. I like to be very explicit in my DbContext implementations around how I tell the story of how an entity gets mapped from an object representation to a relational format, and I tend to favor explicit declarations for each property in my OnModelCreating override. As per my experience, it makes it easier and a lot faster to build up an understanding of how business concepts are represented in a relational format, but Entity Framework comes with a lot of conventions built-in and I could leave a lot of the statements out because they would get picked up by those conventions. So this is not only serving the purpose of instructing Entity Framework on how to persist information in a relational format, but also by being very explicit in telling the story to other developers looking at the code (and often just a future version of myself).

One way of explicitly instructing Entity Framework on how to convert a Value Object based property is to use the inline HasConversion option when mapping properties of an entity in the OnModelCreating override in your DbContext implementation, but if you have multiple properties of the same Value Object type you are better served by overriding the ConfigureConventions method. Then you can define a converter for all references to a type of that Value Object. Now these converters can be defined using inline lambda expressions to quickly get it going, but I tend to opt for a class-based approach (personal taste). In my article Modelling Business Primitives With Value Objects I have implemented a ProductNumber as a Value Object, and let’s instruct Entity Framework on how to deal with it.

Simple ProductNumberConverter implementation

First off, I write a simple converter implementation for my Value Object and in this case I would write the following for converting the ProductNumber:

public class ProductNumberConverter : ValueConverter<ProductNumber, string>
{
    public ProductNumberConverter() : base(
        modelValue => modelValue.ToString(),
        dbValue => ProductNumber.Parse(dbValue))
    {

    }
}

You can see that the ValueConverter<> is generic and it closes a type reference to the model type and the database type. In the case of the above my model type is my Value Object of ProductNumber and the database type is the type abstraction that Entity Framework understands, which in this case is a simple language primitive of string. The constructor of the ValueConverter class takes a lambda for converting from the model representation in the form of:

modelValue => modelValue.ToString()

…and it also takes a lambda for converting from the database type (e.g. a string in this example) to a model representation in the form of:

dbValue => ProductNumber.Parse(dbValue)

I rely on the parsing logic that I’ve implemented in the ProductNumber class, hence I’m pushing the responsibility onto that class where I want to centralize the logic and opinions around product numbers.

Using the converter

Now I can specify that for all references to a type of ProductNumber, I want my converter to be used. I do that my adding to my override of ConfigureConventions method on my DbContext like this:

public class PaymentApiDbContext : DbContext
{
    // ...

    protected override void ConfigureConventions(ModelConfigurationBuilder configurationBuilder)
    {
        // ...

        configurationBuilder
            .Properties<ProductNumber>()
            .HaveConversion<ProductNumberConverter>();
    }
}

When reading the example above, it almost explains to me in plain English how product numbers are handled (or maybe I’ve just looked at this for too long 😊).

Final thoughts

Being explicit when declaring how your information will be persisted has been a preferred practice of mine for a long time. When relying on conventions, sometimes you get too little or way too much, but being explicit about it hopefully gives you what you need. But the more important aspect of it, to me at least, is the communication of intent. You simply declare your intent; for future readers. Now conventions absolutely has its merits, and I use conventions in many places, but my experience has taught me that this is a very good place to invest a bit of extra time on being explicit. The examples above would also reveal the relative low effort and low complexity of doing so.

Thank you for reading this post.
